Item |
HP-P8B |
|
Pitch |
8mm |
|
Density |
15625dots/㎡ |
|
Pixel configuration |
1R1G1B |
|
Module Size |
256mm(W)*128mm(H) |
|
Module Resolution |
32 dots(W)*16 dots(H) |
|
Drive type |
1/4Scanning |
|
Cabinet Siz |
1152mm*768mm*120mm |
|
cabinet Resolution |
128 dots*96 dots |
|
Screen thickness |
180cm |
|
Weight |
45kg |
|
Brightness |
≥5500cd/㎡ |
|
Best viewing angle |
110°(H) /90°(V) |
|
Viewing Distance |
8 ~ 40m |
|
Refresh rate |
≥180Hz/s |
|
Repetition frequency |
60HZ |
|
Brightness adjustment |
256 |
|
Power Consumption(Maximum) |
220V/AC |
|
Maximum power |
600W/m² |
|
Average power |
400~600W/㎡ |
|
Protection Rating: |
IP65 |
|
work environment |
Outdoor |
|
Temperature Range(Operating): / humidity range |
-20℃~+50℃ |
|
Life time |
100000H |
|
Signal |
RF、S-Video、RSBHV、YUV、YC、COMPOSITION |
